Avrotools 66003SM6AV – M6 x 1 Shaft Microstop Countersink Cage Stainless Steel Foot Vacuum Extraction Maximum Cutter Diameter: 0.625” (15.875mm)

High Performance Precision Microstop 66003S Series

Avrotools 66003SM6AV – M6 x 1 Shaft Microstop Countersink Cage Stainless Steel Foot Vacuum Extraction

• Model #
• 66003S – 1/4” – 28 Shaft
• 66003SM6 – M6 x 1 Shaft
• 66003SM8 – M8 X 1 Shaft

number for optional equipment:

• Stainless foot – A60009
• Nylon no mare foot – A600100
• Vacuum Addaptor – A66003

Specifications:

• Spindle mounted on 4 ball bearings.
• Bearings protected by dust shields.
• Stainless steel bearing body.
• Stainless steel lock Nut left hand .
• .275” (7mm) Shank.
• 5/16” (8 mm) Shaft Travel.
• 3/4” (19.05mm) Cutter Capacity.
• 0.0005” (0.0127mm) Increment Depth Adjustment
• Rated at 10,000 RPM
